LiTime Best 36V 100Ah Bluetooth Golf Cart Lithium Battery with Communication Port
LiTime Best 36V 100Ah Bluetooth Golf Cart Lithium Battery with Communication Port
Compatible with most 36V golf cart brands — including Yamaha, E-Z-GO TXT, Club Car, and more.
Up to 35 Miles Range: Built for full days on the course and easy cruising around the neighborhood—up to 35 miles per charge.
Hill Ready Power Output: 2C burst for up to 2 minutes for punchy takeoff and steep climbs, with 600A peak (1s) for heavy loads and 100A continuous output for steady driving.
Bluetooth App Monitoring: See live SOC, voltage, current, and battery status on your phone—less range anxiety, more confident rides.
Bluetooth Password Control: Password-protected pairing lets only you connect, preventing unwanted connections and keeping your battery settings secure.
Ten-Year Value Advantage: Lasts up to 10 years, replacing up to 24× 6V lead-acid batteries over time—helping you save up to 80% on replacement costs.
Lightweight Space Saving Design: Replaces 6× 6V 210Ah lead-acid batteries with one LiTime—85% lighter, takes 50% less space, and uses 70% fewer wires for a cleaner install.
Fast 4 Hour Charging: Reaches 0–100% in about 4 hours with a 43.8V 25A LiFePO4 charger.
EV Grade Cells and BMS Protection: LiTime 5.0 BMS offers 20+ protections, including low-temp cut-off protection. EV-grade LiFePO4 cells are 100% traceable, tested 80+ times, and rated for 4,000+ cycles at 100% DOD.
Real-time Display Monitoring: Plug in the LiTime screen for live battery status with ≥99% data accuracy.
Multi Use Versatility: For golf carts, low-speed electric vehicles (≤25 mph /40 km/h), and marine use.
Power Button and LED Status: Short press to turn on, long press to shut down. LED shows normal battery operation at a glance.
Certified Compliance: FCC, CE, RoHS, UN38.3, UL 2271.
Technical Specifications
Technical Specifications
Battery Specifications
Cell Type: LiFePO₄
Warranty: 5 Years
Cycle Life:
4,000 cycles at 100% DOD
6,000 cycles at 80% DOD
15,000 cycles at 60% DOD
Nominal Voltage: 38.4V
Rated Capacity: 100Ah
Energy: 3,840Wh
Max Expansion (Parallel & Series): 4P1S
Internal Resistance: ≤40mΩ
Certifications: FCC, CE, RoHS, UN38.3, UL-2271
Bluetooth: Yes
Self-Heating: No
BMS (Battery Management System)
BMS Rating: 100A
Max Continuous Output Power: 3,000W (Electric Cart); 3,840W (Energy Storage)
Max Continuous Charge Current: 100A
Max Continuous Discharge Current: 100A
Max Discharge Current (1 Second): 600A
Charging Specifications
Charge Method: CC / CV
Charge Voltage: 43.2V ± 0.6V
Recommended Charge Current: 20A
Temperature Performance
Charge Temperature: 32°F to 122°F (0°C to 50°C)
Discharge Temperature: -4°F to 140°F (-20°C to 60°C)
Storage Temperature: 14°F to 122°F (-10°C to 50°C)
Low-Temperature Protection: Yes
Automatic Discharge Off: Below -4°F (-20°C)
Automatic Charge Off: Below 32°F (0°C)
Automatic Charging Recovery: ≥41°F (5°C)
Physical Specifications
Terminal Type: M8 Bolts
Weight: Approx. 61.06 lbs
Dimensions (L × W × H): 20.47 × 10.55 × 8.66 in (Group 8D Size)
Housing Material: ABS
Protection Rating: IP65
